PV1 Active Probe – 5 GHz

High bandwidth: guaranteed 5 GHz bandwidth with a high linearity and accuracy
Non-proprietary interface: output cable of the probe amplifier has a male SMA connector for attachment to any 50 Ohm instrument
Optimized voltage range: linear performance is guaranteed for low-voltage applications such as MIPI
Miniature and lightweight: probe amplifier is housed in a compact enclosure, enabling attachment in confined spaces
Requires – PV1PSU power supply for the probe amplifier (powers up to 10 probes)
Differential and Single-ended solder-in tips are available via Introspect (part #s 7126 and 7127 respectively)

Name	PV1
Description	PV1 Universal Active Probe – 5 GHz BW
Bandwidth	5 GHz
Output Impedance	50 Ω (SMA connector)
Input Impedance	600 Ω
